53.2 x 106.6 x 19.8 millimetres 2.1 x 4.2 x 0.8 inches
Bounding-Volume:
112.3 cubecentimetres
Mass:
130 grams (battery included)
Embedded-Operating-System:
Microsoft Windows Mobile 5.0 for Pocket PC Phone Edition (Magneto) AKU 3.0
Operating-System-Kernel:
Microsoft Windows CE 5.1.342
CPU:
Intel XScale PXA272
CPU-Clock:
416MHz
Databus-Width:
32bit
CPU-Core:
Intel XScale
Number-of-Transistors:
Level-1-cache:
32KB data cache / 32KB instruction cache
Instruction-set:
ARM v5TE
ROM-capacity:
256MB
RAM-type:
SDRAM
RAM-capacity:
64MB
Expansion-Slots:
SDIO, miniSD
Display:
color transflective TFT
Color-Depth:
18bit/pixel (262144 scales)
Resolution:
240 x 320 (76800 pixel)
Diagonal:
2.4` (61 millimetres)
Viewable-size:
1.4` x 1.9` (36.6 x 48.8 millimetres)
Dot-Pitch:
0.1525 millimetre/pixel
Graphical-Controller:
D-A-converter:
16bit audio sampling, stereo
Audio-Input:
mono microphone
Number-of-speakers:
2 (stereo)
Audio-Output:
stereo
Supported-Cellular-Networks:
GSM 900MHz, GSM 1800MHz, GSM 1900MHz
Supported-Data-Standards:
CSD, GPRS, EDGE
Ring:
192-chord melody (polyphonic)
UART:
RS-232, 115200bit/s
Universal-Serial-Bus:
USB 1.1 client, 12Mbit/sUSB Series Mini-B (mini-USB) connector
Infrared-Gate:
IrDA 1.2115200bit/s (SIR/CIR)
Bluetooth:
Bluetooth 1.2.1
LAN:
Not supported
Wireless-LAN:
802.11b, 802.11g54Mbit/s
Modem:
Not supported
Control-Peripherals:
Positioning-Device:
Touchscreen
Keyboard:
alphanumeric phone keyboard, 12 keys
Directional-Pad:
5-way directional block
Battery:
Lithium-ion, removable
Battery-Capacity:
1300mAh
Avarege-Current:
130 mA
Estimated-Battery-Life:
10 hours
Additional-Features:
GPRS Class 10 voice command vibrating call alert built-in antenna flash macro mode NTSC/ PAL/ SECAM analog TV tuner FM radio Bluetooth stereo audio profile (A2DP)
